Edwards nXDS10i Scroll Vacuum Pump, 0.007 mbar
Item No.
50101116
Nominal rotational speed 1800 rpm Displacement 12.7 m 3 h -1 / 7.5 ft 3 min -1 Peak pumping speed 11.4 m 3 h -1 / 6.7 ft 3 min -1 Ultimate vacuum (total pressure) 0.007 mbar / 0.005 Torr Minimum standby rotational speed 1200 rpm Speed control resolution (percentage of full rotation
Description
| Nominal rotational speed | 1800 rpm |
| Displacement | 12.7 m3h-1 / 7.5 ft3min-1 |
| Peak pumping speed | 11.4 m3h-1 / 6.7 ft3min-1 |
| Ultimate vacuum (total pressure) | 0.007 mbar / 0.005 Torr |
| Minimum standby rotational speed | 1200 rpm |
| Speed control resolution (percentage of full rotation speed) | 1% |
| Pumping speed at minimum rotational speed | 7.5 |
| Maximum continuous inlet pressure | 200 mbar |
| Motor power 1-ph | 280 W |
| Power connector 1-ph | IEC EN60320 C13 |
| Recommended fuse | 10A, 250Vac rms |
| Weight | 25.8 kg / 57 lb |
| Inlet flange | NW25 |
| Exhaust flange | NW25 |
| Noise level | 52 dB(A) |
| Vibration at inlet flange | < 4.5 mms-1 (rms) |
| Leak tightness (static) | < 1x10-6 mbar ls-1 |
| Operating temperature range | 10 to 40 °C / 41 to 104 °F |
